Description
The Taifu JET Auto Peripheral Pump is a self-priming water pump designed for household water supply, pressure boosting, and light utility applications. Engineered for stable operation and durable performance, the JET series delivers reliable suction capacity and consistent head output across various flow conditions.
Key Benefits
- Wide voltage operation for stable performance
- F-class insulation with temperature resistance up to 155°C
- Over-current and debris jamming protection for motor safety
Product Overview
The Taifu JET Auto Peripheral Pump series is built for clean water transfer and pressure boosting in residential and light commercial systems. Featuring a stainless steel welded motor rotor shaft for rust resistance and extended service life, the pump is designed to handle stable suction up to 9 meters while maintaining efficient head performance.
This pump series supports varying power ratings to match household and utility water system requirements.
Ideal Applications
- Residential water supply systems
- Pressure boosting for taps and showers
- Clean water transfer and utility pumping
Working Conditions
| Ambient Temperature | 0°C to +45°C |
| Medium Temperature | Up to +40°C |
| pH Range | 6.5 – 8.5 |
| Solid Impurity Ratio | ≤ 0.1% (Particle size ≤ 0.2 mm) |
Technical Specifications – Model Overview
| Model | kW | HP | Inlet/Outlet | Max Suction (m) | Max Flow (L/min) |
|---|---|---|---|---|---|
| JET60 | 0.37 | 0.5 | 1″ × 1″ | 9 | 53 |
| JET80 | 0.55 | 0.75 | 1″ × 1″ | 9 | 53 |
| JET100 | 0.75 | 1 | 1″ × 1″ | 9 | 50 |
| JET150 (1.5HP) | 1.1 | 1.5 | 1.5″ × 1″ | 9 | 80 |
| JET150 (2HP) | 1.5 | 2 | 1.5″ × 1″ | 9 | 130 |
Performance Head Data (H in meters at Flow Q m³/h)
| Model | 0 | 0.5 | 1 | 1.5 | 2 | 2.5 | 3 | 3.5+ |
|---|---|---|---|---|---|---|---|---|
| JET60 | 32 | 29 | 26 | 22 | 20 | 15 | 10 | – |
| JET80 | 38 | 32 | 27 | 21 | 20 | 16 | 8 | – |
| JET100 | 40 | 36 | 32 | 26 | 20 | 16 | 8 | – |
| JET150 (1.5HP) | 55 | 51 | 48 | 46 | 42 | 36 | 31.8 | 26+ |
| JET150 (2HP) | 50.5 | 50 | 49.4 | 49 | 48 | 47 | 46 | 45+ |
What’s Included
- 1 × Taifu JET Auto Peripheral Pump (selected model)
Learn more about our Warranty Policy or contact us for professional assistance.
