Description
The Taifu ATQB Priming Pump is a self-priming surface water pump engineered for stable water delivery, durability, and low-noise operation. Designed with a full copper motor, copper impeller, and enhanced rust-proof protection, it supports reliable clean water transfer for domestic and light utility applications.
Key Benefits
- Full copper motor with F-grade insulation for extended service life
- Copper impeller reduces rust formation and seizure risk
- Thicker electrophoretic rust-proof layer for improved durability
- Stable water output with low noise performance
- Built-in protection device prevents motor burnout
- Centerless-ground rotor for improved durability
Product Overview
The Taifu ATQB series priming pump is designed to transport clean water and other viscous, non-corrosive liquids. It is not suitable for flammable, explosive, easily gasified, or solid-containing liquids. The pump is compatible with granular or fibrous liquids with a pH value between 6.5 and 8.5.
The allowable volume ratio of solid impurities in the medium must not exceed 0.1%, and particle size must not exceed 0.2 mm. Built for reliability and consistent head performance, it is suitable for residential water boosting and small-scale water transfer applications.
Ideal Applications
- Domestic water supply and boosting
- Clean water transfer applications
- Light agricultural and garden irrigation systems
Technical Specifications – General
| Liquid Type | Clean water and non-corrosive viscous liquids |
| pH Range | 6.5 – 8.5 |
| Max Solid Impurity Ratio | 0.1% |
| Max Particle Size | 0.2 mm |
Technical Specifications – Model ATQB60
| Model | ATQB60 |
| Power (kW) | 0.37 |
| Power (HP) | 0.5 |
| Inlet / Outlet | 1″ × 1″ |
| Max Suction | 8 m |
| Max Flow | 3 m³/h |
Performance Curve – ATQB60
| Flow (m³/h) | Head (m) |
| 0 | 35 |
| 0.5 | 22 |
| 1 | 16 |
| 1.5 | 8 |
| 2 | 2 |
| 2.5 | – |
| 3 | – |
| 3.5 | – |
| 4 | – |
| 4.5 | – |
| 5 | – |
| 6 | – |
| 7 | – |
| 7.5 | – |
| 8 | – |
What’s Included
- 1 × Taifu ATQB60 Priming Pump
